Git Collect

Git Collect is a Jenkins plugin that allows you to register an already existing local Git repository into the Jenkins build data without performing a network fetch, clone, or checkout.

This is ideal for complex pipelines where the source code is retrieved by external scripts, pre-mounted volumes, or other tools, but you still want Jenkins to record the Git revision, branch information, and be compatible as plugin like git-forensic.

• No Network Activity: Strictly operates on the local file system.
• Pipeline Support: First-class support for Jenkins Pipeline via collectGit.
• Accurate Revision Tracking: Distinguishes between the User Intent (Marked Revision, e.g., origin/master) and the Actual Result (Built Revision, e.g., SHA1).
• Compatibility: Generates standard BuildData actions, making it compatible with other plugins that rely on the standard Git plugin data structures.

The plugin exposes the collectGit step.

If you just want to register a repo found in the workspace:

pipeline {
    agent any
    stages {
        stage('Checkout') {
            steps {
                // Assume code is downloaded here by a script/tool
                sh './download_code.sh'
            }
        }
        stage('Register Git Data') {
            steps {
                // Looks for .git in the 'src' folder
                collectGit path: 'src'
            }
        }
        stage('Register Git Data from a marked commit') {
            steps {
                // Looks for .git in the 'src' folder, and reference commit 'markedCommit'
                collectGit path: 'src', markedCommit: '64ed978d54d2db4522a326c3f5cba6f8d4b41f8f'
            }
        }
        stage('Register Git Data from a marked commit, including changelog') {
            steps {
                // Looks for .git in the 'src' folder, and reference commit 'markedCommit'
                collectGit path: 'src', markedCommit: '64ed978d54d2db4522a326c3f5cba6f8d4b41f8f', changelog: true
            }
        }
    }
}

The same revision of a repository is collected into the build once, whichever branch of a parallel stage reaches the same checkout first: a later collectGit reads the same history and registers nothing, so that it is not listed twice in the build. Two collects of one repository at two different revisions are both recorded. The step says so in the build log when it skips.

A collection that brought no new commit - markedCommit resolving to the revision that is checked out - is registered like any other: the changelog is empty and the build shows no changes, but the checkout is recorded, and the repository is listed in the build as it is for a checkout that brought commits.

With changelog: true, every commit of the changelog links to its page on the web frontend of the repository, and every changed file links to its diff. The plugin works the address out from the remote URL and appends the commit part itself, so this is only needed for the repositories it cannot recognise.

There are two ways to say which browser to use, one terse and one complete:

• browserUrl is the base URL of the repository browser, without the +/<sha1> part. The link format still follows the URL, so it reaches the frontends whose links can be told apart by their address.
• browser is a whole repository browser, the same ones the Git SCM offers, and says both the address and the link format. It is what the Repository Browser drop down sets in the job configuration.

GerritHub does not run the gitiles plugin, so its commit pages are not below /plugins/gitiles/<project> but below /c/<project>, and the address guessed from the remote would answer 404:

stage('Register Git Data, linking to GerritHub') {
    steps {
        collectGit path: 'src',
                   markedCommit: 'origin/master',
                   changelog: true,
                   // Commit links then read
                   // https://gerrithub.io/c/amarula/checks-jenkins/+/<sha1>%5E%21
                   browserUrl: 'https://gerrithub.io/c/amarula/checks-jenkins'
    }
}

The commit links and the (diff) links are then Gerrit routes, but the file-name links still use the gitiles +blame/<sha1>/<path> form, which only a gitiles frontend serves: on GerritHub those lead nowhere.

A Gerrit that does run the gitiles plugin is browsed below its plugin path instead, and serves all three:

collectGit path: 'src', changelog: true,
           browserUrl: 'https://gerrit.example.com/plugins/gitiles/amarula/checks-jenkins'

Any other browser can be named outright, for a frontend the plugin would not have recognised or for one whose links it would have built the wrong way:

collectGit path: 'src', changelog: true,
           browser: [$class: 'Gitiles', repoUrl: 'https://gerrit.example.com/plugins/gitiles/amarula/checks-jenkins']

// or any other browser the Git SCM plugin offers, e.g.:
collectGit path: 'src', changelog: true,
           browser: [$class: 'GitLab', repoUrl: 'https://gitlab.example.com/amarula/checks-jenkins/']

Left unset, the address is guessed from the remote URL:

• a github.com, gitlab.com or bitbucket.org remote gets its own frontend;
• a remote shaped like a Gerrit - its host name, an /a/ clone path, a plugins/gitiles path, or the SSH port 29418 - is linked with the gitiles URL format, as in https://gerrithub.io/plugins/gitiles/amarula/checks-jenkins/+/<sha1>%5E%21;
• anything else is linked with the GitHub URL format, as in .../commit/<sha1>.

That guess cannot know about a Gerrit served from a name that says nothing about it and cloned over an anonymous https URL, nor about a self-hosted frontend: browserUrl and browser are what cover those. It reads a little too much as well, since Gerrit's /a/ clone path is the same on the wire as a project that lives in an a directory, and such a remote is linked as a Gerrit until told otherwise.

browserUrl sets the address but not the link format - the plugin still reads the Gerrit markers off the URL to choose between the gitiles and the GitHub forms - so where the format matters, name the browser instead.
